Toyota A type engine

The Toyota A-type engine (Toyota A-type engine ) is a series of water-cooled in- line 4-cylinder gasoline engines of Toyota Motor Corporation. As T-type successor models, mainly Corolla / Sprinter , such as system B segment car, Carina / Corona system and said C-segment vehicles (both 1980s – 1990s had been installed at the time).

Overview

Will be the first as a gasoline engine with a Toyota-made SOHC mechanism of Presidents of the rubber -made timing belt adopted (cog belt) [1]
The combustion chamber uses a wedge-shaped combustion chamber for SOHC head specifications, and a pent roof type combustion chamber for DOHC head specifications.

Production period

1978 July-June 2002 (for domestic use. Overseas use was produced until November 2012.)

Genealogy

See the genealogy of automobile engines in the engine model list .

Model

1A series
1A-U

• Type: SOHC 8 valve single carburetor oxidation catalyst TGP (turbulent flow generation pot) combustion method
• Displacement: 1.452L
• Inner diameter x stroke: 77.5 x 77.0 (mm)
• Compression ratio: 9.0
• Reference output: 59kW (80ps) / 5,600rpm
• Reference torque: 113N ・ m (11.5kg ・ m) / 3,600rpm
• Installed vehicle type (vehicle type)
• (First) First generation Tercel / Corsa (AL10) (Toyota’s first FF model, but with engine vertically installed )

2A series

2A-U

• 2A type engine installed in the second generation Tercel
• Type: SOHC 8 valve single carburetor catalyst
• Displacement: 1.295L
• Inner diameter x stroke: 76.0 x 71.4 (mm)
• Compression ratio: 9.3
• Reference output: 75ps / 6,000rpm
• Reference torque: 10.9kg-m / 3,600rpm
• Installed vehicle type (vehicle type)
  • (First) First generation Tercel / Corsa (AL11)
  • 2nd generation Tercel / Corsa / First generation Corolla II (AL20)

2A-LU

• Type: SOHC 8 valve single carburetor engine horizontal catalyst
• Displacement: 1.295L
• Inner diameter x stroke: 76.0 x 71.4 (mm)
• Installed vehicle type (vehicle type)
• (First) 5th generation Corolla / Sprinter (AE80)

3A series

3A-U

• 3A type engine (photograph is for horizontal FF vehicle)
• Type: SOHC 8 valve single carburetor catalyst
• Displacement: 1.452L
• Inner diameter x stroke: 77.5 x 77.0 (mm)
• Compression ratio: 9.3
• Reference output: 83ps / 5,600rpm
• Reference torque: 12.0kg-m / 3,600rpm
  • Installed vehicle type (vehicle type)
  • (First) 4th generation Corolla / Sprinter (AE70 FR )
  • First generation Tercel / Corsa (AL12)
  • 7th generation corona (AT140 FR )
  • 2nd generation Tercel / Corsa (AL21 / 25)
  • First Corolla II (AL21)
  • First Sprinter Caribbean (AL25G)
  • 4th Corolla Levin / Sprinter Trueno ( AE85 FR )

3A-HU

• Type: SOHC 8 valve single carburetor (variable venturi type) catalyst
  • Displacement: 1.452L
• Inner diameter x stroke: 77.5 x 77.0 (mm)
• Compression ratio: 9.3
• Reference output: 86ps / 6,000rpm
• Reference torque: 12.3kg-m / 4,000rpm
• Installed vehicle type (vehicle type)
• 2nd generation Tercel / Corsa / First generation Corolla II (AL21)

3A-SU

• Type: SOHC 8 valve twin carburetor catalyst
• Displacement: 1.452L
• Inner diameter x stroke: 77.5 x 77.0 (mm)
• Installed vehicle type (vehicle type)
  • 2nd generation Tercel / Corsa / First generation Corolla II (AL21 / AL25) *
  • Hatchback is SR sports package only, Tercel sedan / Corsa sedan is 4WD superlative grade only
  • First Sprinter Caribbean (AL25G) * AVⅡ & AVⅡ Touring Special only

3A-LU

• Type: SOHC 8-valve single carburetor engine horizontal mounting catalyst
  Displacement: 1.452L
• Inner diameter x stroke: 77.5 x 77.0 (mm)
• Installed vehicle type (vehicle type)
• (First) 5th generation Corolla / Sprinter (AE81)
• (First) First Corolla FX (AE81)
• 8th Corona (AT150, sedan / liftback)
• First MR2 (AW10)

4A series

4A-C

• Type: SOHC 8 valve single carburetor catalyst
• Displacement: 1.587L
• Inner diameter x stroke: 81.0 x 77.0 (mm)
• Compression ratio: 9.0
• Reference output: 74ps / 4,800rpm
• Installed vehicle type (vehicle type)
  • (First) 4th generation Corolla series (AE71L FR )-* North American specifications only
  • 5th generation Corolla 3-door coupe / 2-door coupe (AE86L FR) -* North American specifications only

4A-LC

• Type: SOHC 8-valve single carburetor engine horizontal mounting catalyst
• Displacement: 1.587L
• Inner diameter x stroke: 81.0 x 77.0 (mm)
• Compression ratio: 9.3
• Reference output: 78ps / 5,600rpm
• Installed vehicle type (vehicle type)
  • (First) 5th generation Corolla (AE82 FF )-* Excluding Japanese specifications

4A-L

• Type: SOHC 8-valve EFI engine horizontal mounting catalyst
• Displacement: 1.587L
• Inner diameter x stroke: 81.0 x 77.0 (mm)
• Reference output: 84ps / 5,600rpm
• Installed vehicle type (vehicle type)
• (First) First Carina II (AT151 FF)-* Exclusively sold in Europe
• 4th Celica (AT160 FF)-* Excluding Japanese specifications
• 5th generation Corolla (AE82 FF)-* Excluding Japanese specifications

4A-ELU

• Type: SOHC 8-valve EFI engine horizontal mounting catalyst
• Displacement: 1.587L
• Inner diameter x stroke: 81.0 x 77.0 (mm)
• Compression ratio: 9.0
• Reference output: 100ps / 5,600rpm
• Reference torque: 14.0kg ・ m / 4,000rpm
• Installed vehicle type (vehicle type)
• (First) 5th generation Corolla / Sprinter 5-door sedan 1600ZX (AE82)
  5th Corolla / Sprinter (AE82)
• (First) First-generation Corolla FX 1600SR-EFI (AE82)

4A-F

Type: DOHC 16 valve single carburetor high mechanical twin cam
Displacement: 1.587L
Inner diameter x stroke: 81.0 x 77.0 (mm)
Compression ratio: 9.5
Reference output: 67kW (91ps) / 6,000rpm
Reference torque: 132N ・ m (13.5kg ・ m) / 3,600rpm
Installed vehicle type (vehicle type)
(First) 6th generation Corolla / Sprinter 4WD (AE95)

4A-FE

4A-FE type engine for 2nd generation Geo Prism (AE111)
Type: DOHC 16 valve EFI high mechanical twin cam
Displacement: 1.587L
Inner diameter x stroke: 81.0 x 77.0 (mm)
Compression ratio: 9.5
Reference output / torque (1): 74kW (100ps) / 5,600rpm 137N ・ m (14.0kg ・ m) / 4,400rpm
Reference output / torque (2): 85kW (115ps) / 6,000rpm 147N ・ m (15.0kg ・ m) / 4,800rpm
Reference output / torque (3): 81kW (110ps) / 5,800rpm 149N ・ m (15.2kg ・ m) / 4,600rpm
Installed vehicle type (vehicle type)
Corolla / Sprinter system
(First) Second generation Sprinter Caribbean (AE95G)
3rd generation Sprinter Caribbean (AE111G / AE114G)
6th / 7th / 8th Corolla / Sprinter (AE95 / AE101 / AE104 / AE111 / AE114)
6th and 7th generation Corolla Levin / Sprinter Trueno (AE101 / AE111)
3rd generation Corolla FX1600SJ (AE101)
(First) Corolla Ceres (AE101)
(First) Sprinter Marino (AE101)
The first Corolla Spacio (AE111)
Geo Prism (first generation: AE90 series equivalent and second generation: AE100 series equivalent)
Corona / Carina
10th generation corona (AT190)
2nd generation Corona SF (AT190)
5th Carina SG / SG Extra 4WD (AT175)
5th and 6th generation Carina S Limited (AT171 / AT190)
11th generation Corona Premio (AT210 lean burn )

4A-FHE

Type: DOHC 16-valve EFI-S High mechanical twin cam
Displacement: 1.587L
Inner diameter x stroke: 81.0 x 77.0 (mm)
Compression ratio: 9.5
Reference output: 81kW (110ps) / 6,000rpm
Reference torque: 142 N ・ m (14.5 kg ・ m) / 4,800 rpm
Installed vehicle type (vehicle type)
5th Carina S Limited (AT171)
Sprinter Caribbean (AE95G, 1990-1995)’

4A-GEU (4 valves)

“For more information Toyota · 4A-GE see”
Type: DOHC 16-valve EFI catalyst
Displacement: 1.587L
Inner diameter x stroke: 81.0 x 77.0 (mm)
Installed vehicle type (vehicle type)
(First) 4th generation Corolla Levin / Sprinter Trueno ( AE86 FR )
7th generation Corona 1600GT / GT-R (AT141)
3rd Carina 1600GT / GT-R (AA63)
4A-GELU (4 valves)
“For more information Toyota · 4A-GE see”
Type: DOHC 16-valve EFI engine horizontal catalyst
Displacement: 1.587L
Inner diameter x stroke: 81.0 x 77.0 (mm)
Compression ratio: 10.3
Reference output: 103kW (140ps) / 7,200rpm
Reference torque: 147N ・ m (15.0kg ・ m) / 6,000rpm
Installed vehicle type (vehicle type)
(First) First MR2 (AW11)
First and second generation Corolla FX 1600GT (AE82 / AE92)
5th Corolla / Sprinter 1600GT (AE82)
6th generation Corolla / Sprinter 1600GT (AE92)
5th Corolla Levin / Sprinter Trueno (AE92)
(First) Sprinter Cielo 1600GT (AE92)

4A-GE (5 valves)

4A-GE type engine for 7th generation Carina (AT210)
“For more information Toyota · 4A-GE see”
Type: DOHC 20 valve EFI VVT
Displacement: 1.587L
Inner diameter x stroke: 81.0 x 77.0 (mm)
Compression ratio: 11.0
Reference output: 121kW (165ps) / 7,800rpm
Reference torque: 162N ・ m (16.5kg ・ m) / 5,600rpm
Installed vehicle type (vehicle type)
7th generation Corolla / Sprinter 1600GT (AE101)
(First) Corolla Ceres (AE101)
(First) Sprinter Marino (AE101)
3rd generation Corolla FX 1600GT (AE101)
6th Corolla Levin / Sprinter Trueno (AE101)
7th generation Corolla Levin / Sprinter Trueno (AE111)
5th Carina G Limited (AT171)
7th Carina 1600GT (AT210)
8th Corolla / Sprinter 1600GT (AE111)

4A-GZELU (4A-GZE)

“For more information Toyota · 4A-GE see”
Type: DOHC supercharger 16 valve EFI engine horizontal catalyst
Displacement: 1.587L
Inner diameter x stroke: 81.0 x 77.0 (mm)
Compression ratio: 8.9
Reference output: 125kW (170ps) / 6,400rpm
Reference torque: 206N ・ m (21.0kg ・ m) / 4,400rpm
Installed vehicle type (vehicle type)
(First) First MR2 (AW11)
5th Corolla Levin / Sprinter Trueno 1600GT-Z (AE92)
6th generation Corolla Levin / Sprinter Trueno 1600GT-Z (AE101)
5A series
It is the same 1.5-liter class as 1A and 3A, but the displacement has slightly increased due to the expansion of the bore.

5A-F

Type: DOHC 16 valve single carburetor high mechanical twin cam
Displacement: 1.498 L
Inner diameter x stroke: 78.7 x 77.0 (mm)
Compression ratio: 9.6
Reference output: 63 kW (85 ps) / 6,000 rpm
Reference torque: 123 N ・ m (12.5 kg ・ m) / 3,600 rpm
Installed vehicle type (vehicle type)
(First) 6th generation Corolla / Sprinter (AE91 previous term)
(First) Sprinter Cielo (AE91 previous term)
2nd generation Corolla FX (AE91 previous term)
5th Corolla Levin / Sprinter Trueno (AE91 previous term)
9th Corona (AT170 previous term)
First Corona SF (AT170 first term)
5th generation Carina (AT170 previous term)

5A-FE

5A-FE type engine for 8th generation Corolla sedan (AE110)
Type: DOHC 16 valve EFI high mechanical twin cam
Displacement: 1.498 L
Inner diameter x stroke: 78.7 x 77.0 (mm)
Compression ratio: 9.8
Reference output / torque (1): 69 kW (94 ps) / 6,000 rpm 128 N ・ m (13.1 kg ・ m) / 3,200 rpm
Reference output / torque (2): 77 kW (105 ps) / 6,000 rpm 135 N ・ m (13.8 kg ・ m) / 4,800 rpm
Reference output / torque (3): 74 kW (100 ps) / 5,600 rpm 137 N ・ m (14.0 kg ・ m) / 4,400 rpm
Installed vehicle type (vehicle type)
(First) 5th, 6th, 7th generation Corolla Levin / Sprinter Trueno (AE91 latter term / AE100)
(First) Second-generation Corolla FX (AE91)
(First) Sprinter Cielo (AE91 latter half)
6th, 7th, 8th generation Corolla / Sprinter (AE91 latter half, AE100, AE110)
(First) Corolla Ceres (AE100)
(First) Sprinter Marino (AE100)
8th generation Corolla / Sprinter (AE110 second half)
9th Corona (AT170 late)
First generation Corona SF (AT170 second half)
5th generation late, 6th generation, 7th generation Karina (AT170 latter term, AT192, AT212)
Soluna (AL50) * Southeast Asian monopoly model

5A-FHE

Type: DOHC 16-valve EFI-S High mechanical twin cam
Displacement: 1.498 L
Inner diameter x stroke: 78.7 x 77.0 (mm)
Compression ratio: 9.6
Reference output: 77kW (105 ps) / 6,000 rpm
Reference torque: 132 N ・ m (13.5 kg ・ m) / 4,800 rpm
Installed vehicle type (vehicle type)
6th generation Corolla SE Limited G / Sprinter SE Saloon G (AE91 / late model only)
5th Corolla Levin / Sprinter Trueno ZS (AE91 / late model)
Sprinter Cielo Xs (AE91, late)
2nd generation Corolla FX ZS / VS (AE91 / late model)

6A series

6A-F

Type: DOHC 16 valve
Displacement: 1.397L
Inner diameter x stroke: 76.0 x 77.0 (mm)
Reference output: 61kW (83ps)
Reference torque: 117N ・ m (11.9kg ・ m)

7A series

7A-FE

7A-FE

Type: DOHC 16 valve EFI high mechanical twin cam
Displacement: 1.762L
Inner diameter x stroke: 81.0 x 85.5 (mm)
Compression ratio: 9.5
Reference output: 85kW (115ps) / 5,400rpm
Reference torque: 155N ・ m (15.8kg ・ m) / 2,800rpm
Installed vehicle type (vehicle type)
(First) 6th generation Carina (AT191)
3rd Sprinter Caribbean (AE115G)
11th generation Corona Premio (AT211)
7th generation Carina (AT211)
First Corolla Spacio 4WD vehicle (AE115)
After the first Cardina MC (AT191G) lean burn specification
2nd generation Cardina (AT211G)
Chevrolet prism

8A series

8A-FE

Type: DOHC 16 valve EFI high mechanical twin cam
Displacement: 1.342L
Inner diameter x stroke: 78.7 x 69.0 (mm)
Compression ratio: 9.3
Reference output: 64kW (87ps) / 6,000rpm
Reference torque: 110N ・ m (11.2kg ・ m) / 3,200rpm
Installed vehicle type (vehicle type)
(First) Natsuri Vita N3
